Center Hilchenbach

Manufacturing

Engineering and production under one roof

  • Our Hilchenbach production shop covers a total of 40,000 m2 and ranks among the most modern anywhere in the world
  • Engineering and production under one roof to ensure efficient order processing
  • Production of core metallurgical and rolling mill components ranging from sophisticated welded structures to mechanically manufactured parts
  • SMS TECademy facility for customer training
  • LernWERK as a blueprint for apprenticeships
Center Hilchenbach image Center Hilchenbach image Center Hilchenbach image Center Hilchenbach image

Competencies

Welding Manufacturing image Welding Manufacturing image Welding Manufacturing image Welding Manufacturing image

CARE AT EVERY STEP

  • Unit weight: up to 250 t
  • Welding processes: E, MIG, MAG, WIG, UP, RES, and special welding technologies
  • Car-hearth annealing furnace: up to 3,500 x 5,500 x 7,000 mm
  • Surface treatment: open jet blasting and priming booths
Mechanical production image Mechanical production image Mechanical production image Mechanical production image

TURNING, DRILLING, MILLING, GRINDING, SHAPING

  • CNC center lathes: swing dia- meter up to 1,400 mm, turning length up to 10,000 mm
  • CNC carousel turning machines: swing diameter max. 4,500 mm, turning height max. 2,500 mm, with grinding, milling and drilling equipment
  • CNC turning and milling center: swing diameter max. 1,200 mm, turning length max. 8,400 mm
  • CNC boring mills: working area x = 21,000 mm, y = 6,500 mm with rotary clamping device (Ø 1,000 mm) and angled milling heads for machining in all axis directions; rotary table with dimensions 4,500 x 5,000 mm
  • CNC portal milling machines: portal opening width 5,200 mm, portal opening height 5,000 mm, milling length 16,000 mm with angled milling heads in all axis directions
  • Crane capacity: 250 t
  • CNC grinding machines
  • CNC vertical shaping machine: shaping stroke up to 1,500 mm
Assembly and test field image Assembly and test field image Assembly and test field image Assembly and test field image

ASSEMBLY PROGRAM AND FUNCTIONAL TESTS

  • Lifting capacity: up to 400 t, lifting height up to 17 m
  • Functional testing: hydrau- lic control systems with pump pressures up to 600 bar
  • Cylinder pressure testing: up to 3,000 t
  • Water tests: up to 800 l/min · Multi-plate filter tests
  • Paint finishing plant
Measuring image Measuring image Measuring image Measuring image

HIGH PRODUCTION QUALITY IS OUR HALLMARK

  • Non-destructive testing
  • Three-coordinate measuring machine
  • Gear inspection machine

Gear wheel production

Tooth Types

​​​​​​​External teeth

  • Diameter: 100 to 6,000 mm
  • Module: up to 40 mm
  • Weight: max 100 t

Internal teeth

  • Pitch diameter: up to 2,000 mm
  • Module: up to 22 mm
Gear wheel production - Video Gear wheel production - Video Gear wheel production - Video Gear wheel production - Video

Gear wheel production

SMSgroup Image SMSgroup Image SMSgroup Image SMSgroup Image

Design and assembly of a radial gear unit for a forging plant
